Product overview:
It could be applies to seafood, seafood, cold water machine, as well as the need for refrigeration, heating and automatic switching equipment.

Features
1 automatic conversion of refrigeration and heating mode;
2 return differential temperature control mode;
3, temperature correction;
4, refrigeration control output delay protection;
5, ultra range and sensor fault alarm.

Function
Refrigeration, heating, single sensor, temperature correction.

Technical parameters
Measuring range: -50 to 99 DEG c.;
* temperature resolution: 0.1 degrees;
Some measurement accuracy: + 1 DEG C; (-50 to 70 DEG C);
To power consumption: less than 3W;
Some sensor: NTC sensor 1
* power supply: 220VAC+10%/-10%, 50/60Hz;
To relay output capacity:
Refrigeration: 10A/250VAC, heating: 10A/250VAC,
To the front panel protection grade: IP65;
To environment temperature: 0 to 60 DEG c;
Storage temperature: -30 to 75 DEG c.;
Some relative humidity: 20 ~ 85% (no condensation).

size
Panel size: 75 * * 34.5 long width (mm);
To install hole size: 71 x 29 width (mm);
To machine size: length 75 x 34.5 x width depth (mm) 85

Packing details:

100pcs/carton,Meas:42*30*34cm.G.W:25.5KG
